Dental Imaging VET // ScanX DR X-ray Sensor
-
-
Acceptance
Sharp detailed image quality -
Benefit
Increased volume and eliminate dark room -
Crystal clear
Superior Image Quality for better diagnostics -
Efficient
Workflow tailored
to your needs -
VET specific
Intuitive operation, focused on the veterinary practice
-
-
Uncover treatment opportunities you cannot afford to miss // ScanX DR VET dental X-ray sensor
Quick image transmission with CMOS
The modern CMOS technology of the ScanX DR Sensor ensures the fast transmission of high-resolution images. The new scintillator layer reduces scatter and concentrates the energy to positively influence the best image quality.
Superior Image Quality for better diagnostics
Exceptional diagnostic image quality helps you detect pathologies under the gum that are not visible during a routine exam without radiographs.
Hygiene Management
Hygiene cover and wipe-disinfected to prevent cross contamination.
-
Discover the benefits of Direct Radiography // ScanX DR VET dental X-ray sensor
Digital Radiography (DR) provides real-time high-resolution imaging after being exposed with your x-ray generator.
The high-resolution latent image is automatically displayed on your computer screen in a matter of seconds.
The optimized digital images can be shared directly with other users and easily archived.SIMPLEST WORKFLOW
INSTANTANEOUS IMAGE ACQUISITION
HIGHEST IMAGE QUALITY
HIGHEST RESOLUTION AT 20 LP/MM
-
Excellent Image quality due to design and inovation // ScanX DR VET dental X-ray sensor
-
-
Technical data // ScanX Duo
Dimensions (H x W x D) 6.3 x 33.1 x 43 mm Active sensor surface 36 x 26 mm Pixel size 19 x 19 μm Number of pixels 1,368 x 1,896 = 2,593,728 Theoretical resolution 26.3 LP/mm Effective resolution 20.0 LP/mm Greyscale 16 bit (65,536) Cable length 2.5 m PC connection USB 2.0, USB 3.0 compatible USB extension 1 m (standard) Service life > 400,000 images * Warranty 2 Years
* If used properly as described in the usage instructions with an average detector dose of 50 μGy
